roduct show
| 代號(hào) | 軟管 | 尺寸 | |||
|---|---|---|---|---|---|
| PART NO. | 公稱內(nèi)徑 DN | 標(biāo)號(hào) DASH | L | L1 | D2 |
| S60011-04-04 | 6 | 04 | 31 | 25 | 11 |
| S60011-05-05 | 8 | 05 | 33.5 | 26 | 13 |
| S60011-06-06 | 10 | 06 | 34 | 26 | 15 |
| S60011-08-06 | 10 | 06 | 34.5 | 26 | 18 |
| S60011-08-08 | 13 | 08 | 34.5 | 26 | 18 |
| S60011-10-10 | 16 | 10 | 39 | 30 | 20 |
| S60011-12-12 | 19 | 12 | 40.5 | 31 | 24 |
| S60011-16-14 | 22 | 14 | 41 | 31 | 30 |
| S60011-16-16 | 25 | 16 | 42 | 31 | 30 |
